Single Axis Stepper Motor Arbitrary Programmable 220V 40KHz KH-01

Produs nou ambalat!

Daca va intereseaza lasati un nr de telefon!

Specification:
- Condition: 100% brand new and high quality
- Product Name: Single Axis Stepper Motor Controller
- Power Supply: AC 220V (power supply error is not greater than ± 15%)
- Instruction Specification: Arbitrary Programmable
- Max Output Frequency: 40KHz
- Output Frequency Resolution: 1Hz
- Program Number: 99
- Input: 6 (Optoelectronic Isolation)
- Output: 3 (Optoelectronic Isolation)
- Continuous Displacement Range: -7999999~7999999
- Rise and fall curve: 2 (Optimized)
- Working Status: Automatic running state, manual running state, program editing state, parameter setting state
- Display Function: 8-bit digital tube display, manual/ automatic state display, run/ stop state display, step/ count value/ program display, edit program, parameter display, input/ output state display, CP pulse and direction display
- Automatic operation function: It can be edited, and the start and stop of automatic operation can be controlled by the panel key and the level of the terminal
- Manual operation function: Adjustable position (manual click-to-move speed and click-to-move steps can be set)
- Parameter setting function: can set take-off frequency, speed curve, reverse clearance, manual length, manual speed, interrupt jump line number and return speed
- Program editing function: can be inserted arbitrarily, delete modifiable program.The utility model has the functions of skip-line number, 0 data determination, ultra-long statement number and ultra-short judgment function
- 0-return function: can automatically return to 0 in both directions
- Programming instructions: a total of 14 instructions;technical support
- External operation function: Through parameter setting and programming, external interrupt operation can be performed by adding switch on A operation and B operation terminal
