General Specifications
Machine type
Colour Laser Multifunctional (Reader/Printer separated)

Core functions
Print, Copy, Scan, Send and Optional Fax

Processor
1.8 Ghz

Warm-up Time
Approx. 31 sec from power ON (Normal mode),
7 sec from power ON (Quick Start mode)

Recovery from Sleep mode
18 sec (iR-ADV C5240i EQ80), 15 sec (iR-ADV C5255i EQ80)

Memory
2.5 GB

Hard Disk drive
Standard 320 GB Hard Disk Drive
(usable space 160 GB)

Interface type
USB 2.0 Hi-Speed, Ethernet: 1000BaseT/100Base-TX/10Base-T, 1 x USB Host (2.0)

Network protocols
TCP/IP* (LPD/Port 9100/WSD/IPP/IPPS/SMB/ FTP), IPX/SPX (NDS, Bindery), AppleTalk
*IPv4/IPv6 support

Control Panel
21.3 cm (8.4 inch) TFT SVGA LED Backlight Colour Touchscreen

Dimensions (W x D x H)
C5240i: 620 mm x 712 mm x 1182 mm
C5255i: 620 mm x 715 mm x 1201 mm

Installation Space (W x D)
850 mm x 1196 mm (iR-ADV C5255i EQ80 + Multi-purpose tray + Cassette drawers open)
850 mm x 1164 mm (iR-ADV C5240i EQ80 + Multi-purpose tray + Cassette drawers open)

Weight
(including CASSETTE FEEDING UNIT)
C5240i: 172 kg
C5255i: 177 kg

Operating Environment
Temperature: 10 to 30°C (50 to 86°F)
Humidity: 20 to 80 % RH (no condensation)

Power Source
220-240 V (±10 %), 50/60 Hz (±2 Hz),
4.3-5.6 Amp

Power Consumption
Maximum: Approx. 1.8 KW (iR-ADV C5255i EQ80),
1.5 KW (iR-ADV C5240i EQ80)
Standby: Approx. 110 W
Energy Saver Mode: Approx. 60 W
Sleep mode: Approx. 0.8 W or less*
TEC rating (As per Energy Star v2.0) 2.9kwh (iR-ADV C5255i EQ80), 2.20kwh iR-ADV C5240i EQ80
* 1 watt sleep mode may not be possible in all circumstances, please refer to the User Guide for more information.

Noise Levels
Sound Pressure*
C5255i EQ80: 53dB, C5240i EQ80 51dB
Standby: C5255i EQ80: 31 dB,
C5240i EQ80: 25 dB
*Declared noise emission in accordance with ISO 7779

Software and printer management
iW Management Console for centralised management of the device (Consumables and error monitoring and alerts, address book, configuration and firmware updating, MEAP applications distribution, meter capture, driver and resource management);
Compatible with eMaintenance services via embedded RDS (Enables meter capture, automatic consumables management and remote diagnostics);
Content Delivery System (Remote distribution of firmware, iR options and MEAP applications);
Remote User Interface (RUI); Network ScanGear; NetSpot Device Installer;
MEAP (Multifunctional Embedded Application Platform); MEAP Web

Security Features
Standard: IP/Mac Address Filtering, IPSEC, SNMP V3.0, IEEE 802.1X, Trusted Platform Module (TPM), Secure Print, HDD Password Lock, HDD Erase, Universal Login Manager, Department ID, SSO-H, Mailbox, Access Management System. TLS 1.2
Optional: Encrypted Secure Print and Secure Watermarks, Encrypted PDF, User and Device signatures.
The following items require uniFLOW Online: Scan to Cloud, Print from Cloud, My Print Anywhere
